HYUNDAI HiT-H500CF-BF(ZB) Bifacial module, Premium N-Type HJT (Heterojunction) technology (black frame)

HD Hyundai Energy Solutions HiT-H500CF-BF(ZB) is a high-efficiency premium photovoltaic panel designed for rooftop and ground installations - both in residential and commercial systems. It uses the latest N-type HJT silicon cell technologies and a bifacial (double-sided) design, which allows for additional energy acquisition from reflected light.

High power and efficiency:

• Rated power: 500 Wp – high efficiency under standard sunlight conditions
• Module efficiency: approx. 22.3 – 22.5% – one of the highest efficiencies in the class of 500 Wp panels
• N-type HJT cell technology (heterojunction) – low power degradation and better performance in low light
• Bifacial design: double-sided cells generate additional energy from the rear side with reflected light, which increases the real energy yield of the system

Solid construction:

• Dimensions: 1960 × 1134 × 30 mm
• Weight: approx. 27.1 kg – stable and durable construction
• Glass-glass module: double tempered glass increases resistance to weather and mechanical factors
• Bifaciality: ~90% ±5% – high energy production rate from the back of the panel
• Connectors: MC4/MC4-EVO2 – compatible with modern PV installations
• Connection box: IP68 and 3 bypass diodes - increased resistance and operational safety
• Number of modules on the pallet: 36 pieces
• Number of pallets in the container: 24

Performance and durability:

• Low temperature coefficient: Pmax -0.24%/°C – lower losses at high temperatures
• Temperature operating range: from -40 °C to +85 °C – stable operation in changing climatic conditions
• Maximum system voltage: 1500 V DC – full compatibility with modern inverters
• Mechanical resistance: solid structure adapted to heavy snow and wind loads (standard ~5400/2400 Pa)

Warranties and reliability:

• Product warranty: 30 years - protection of materials and workmanship
• Performance warranty: 30 years – guaranteed power after 30 years approx. 90.3% of nominal power
• Low power degradation in the first year (~1%) and stable, linear degradation in subsequent years (~0.30% per year)

The Hyundai HiT-H500CF-BF(ZB) panel is a perfect combination:

• modern N-type HJT cell technology
• high efficiency and power of 500 Wp,
• bifacial construction with the possibility of additional energy gain
• aesthetics and durability of workmanship,
• long-term warranty and stable operating parameters.
